Celo.Cardiomyocytes

Celo.Cardiomyocytes are a highly pure and electrophysiologically active population of iPSC-derived cardiomyocytes, a product suitable for all types of applications.

2a2v DAPI_20ms.png

It's all about
 Quality  Cardiomyocytes

Celo.Cardiomyocytes are suitable for all types of applications, including your next experiment. These cells are derived from induced Pluripotent Stem Cells (iPSCs) using proprietary protocols which optimize the user experience by prioritizing purity, reproducibility, and electrophysiology. We strive to provide fully functional human cardiomyocytes. Celo.Cardiomyocytes are available in two formats: 2 million vials & 5 x million cell vials. Reach out to us for a quote!

Quality Cells

- ISO 9001-certified Quality Control

-Validated extensively in peer-reviewed journals and application notes.

-Electrophysiology-focused product development

Quality Research

- Consistent Results (low variability)

-High Sensitivity to electrophysiological changes from drug treatment.

-Serum-free media-fo prevents unwanted interactions & increases biological relevance

Celo.Cardiomyocytes

Download the Celo.Cardiomyocytes product brochure as a PDF file for general information.
For additional information, please contact
info@celogics.com

대지 1_4x-8.png

Validated Quality

Celo.Cardiomyocytes have been validated on multiple platforms (Curi Bio Mantaray, Axion Maestro, Nanion Cardioexcyte96, ACEA CardioECR, etc). The quality control process is central in ensuring that all users get accurate and consistent results as well.

Celo.Cardiomyocytes morphology during
Cell Culture

12-well culture plates
The above images were taken from a 12-well culture plate on days 1~14 post-thawing (magnification 100x). Celo.Cardiomyocytes were seeded following the Celo.Cardiomyocytes User Guide at a plating density of 150,000 cells/㎠.

The Celo.Cardiomyocytes recover quickly upon thawing to start spontaneous beating 2 days later and stabilize over time (45~60 bpm on DIV7). The Celo.Cardiomyocytes readily form a single synchronous monolayer which enhances both reproducibility and accuracy of assays.​



48-well culture plate
Axion Maestro 48 well MEA plate DIV1.jpg

DIV 1

Axion Maestro 48 well MEA plate DIV3.jpg

DIV 3

Axion Maestro 48 well MEA plate DIV5.jpg

DIV 5

Axion Maestro 48 well MEA plate DIV7.jpg
Axion Maestro 48 well MEA plate DIV11.jpg
Axion Maestro 48 well MEA plate DIV14.jpg

DIV 7

DIV 11

DIV 14

The above images were taken from a 48well Axion Citoview MEA plate 1~14 days post-thawing (magnification 100x). Please note that the Celo.Cardiomyocytes were seeded following the Celo.Cardiomyocytes Maestro Application Protocol.

Celo.Cardiomyocytes express
Ventricular cardiomyocyte-specific markers

30,000 cells were seeded on Matrigel on a 9 mm coverslip and cultured for 7 days before fixation. Immunocytochemistry was performed by incubating primary antibodies at the concentrations recommended by the respective suppliers at RT for 1 hour.

Celo.Cardiomyocytes express typical ventricular cardiomyocyte markers and structural characteristics which are indicative of the appropriate contractile functionality of these cells. In particular, the Celo.Cardiomyocytes demonstrate high expression of Connexin 43, a gap junction protein, which suggests high interconnectivity and synchronicity.

Fluorescence staining

Celo.Cardiomyocytes demonstrates
Human cardiomyocyte-like electrophysiology

Patch Clamp (Nanion Patchliner)
patch clamp.jpg

Celo.Cardiomyocytes demonstrated a high success rate and low variability in the sodium currents (INa). It was possible to measure a dose-dependent block of sodium currents by TTX (A) and effects specific to INa, Late by ATX-II (enhancer), and Ranolazine (blocker) were also easily observable. Finally, calcium channel activation by BayK and inhibition by Nifedipine could also be detected in changes of the APD90. These results demonstrate that the Celo.Cardiomyocytes express the correct ion channels and can readily be used in pharmacology applications.

Dynamic Clamp (Nanion Patchliner Dynamite8)
dynamic clamp.jpg

Celo.Cardiomyocytes demonstrated great results in dynamic clamp experiments on the Nanion Patchliner with the Dynamite8 add-on. In A, it was possible to record adult-ventricular-like action potentials with the Celo.Cardiomyocytes at physiological temperature. In B & C, the effects of calcium channel activation (BayK) and inhibition (Nifedipine) could be assessed also in the presence of dynamic clamping.

CardioExcyte96

Celo.Cardiomyocytes demonstrated low inter-well variability when tested on the Nanion CardioExcyte 96. High reproducibility of Impedance and EFP signals facilitated compound testing experiments (Nifedipine & Dofetilide). Concentrations were increased by consecutive treatments of 10% media changes and matched the expected results, validating the cardiomyocyte properties.

FLEXcyte96

On Nanion’s FLEXcyte 96 which uses soft substrates to mature the cardiomyocytes, the Celo.Cardiomyocytes demonstrated high responsiveness to Isoproterenol and were able to detect positive inotropic effects after just 7 days of culture.

Spontaneous Baseline (Axion Maestro)
MEA baseline.png
 MEA drug response (Axion Maestro)

Celo.Cardiomyocytes demonstrated low variability, good synchronicity, and good compound reactivity with Nifedipine, E4031, Dofetilide, and Mexiletine on the Axion Maestro. Our QC process makes sure every batch of cells behaves similarly and the above data is available for each vial upon request. We also make sure these results are reproducible independently of which platform you choose to do the MEA assay on.
